Data warehouse boxes

All database applications can be divided into 2 classes: OLTP and data warehouses. OLTP stands for Online Transactions Processing. It's easy to explain the difference between them by an example.

Imagine yourself buying groceries at your local supermarket. When you are done filling your shopping basket and finally come to checkout, here’s what happens:

  • A shopping assistant at the checkout register picks up your first item and scans its barcode. The computer built into the register turns the barcode into a series of characters and digits and queries the store’s database for the item’s description, price and picture. Then it adds the item into your virtual shopping cart.

  • You reach for your next item and all of those steps happen again: a few queries sent to the database, a few tables updated. And then again and again, until your basket is empty.

  • You swipe your credit card. The shop’s system sends a request to the credit card processing centre. It checks that you card is valid and that you are not over your credit limit. Then it asks you for your pin code, verifies it, and if all the checks are successful, withdraws the money.

  • Then the groceries you bought are marked as sold in the inventory control system. A receipt is printed, and the virtual shopping basket is cleared. That’s it. Thank you for shopping with us.

It probably took you less than 5 minutes to go through the register. But the number of database queries and updates it resulted in was likely in hundreds. Now multiply that by the number of checkout registers in the shop, and you’ll get the picture. Checkout register is a typical OLTP system.

OLTP applications are characterized by large volume of atomic database transactions: retrieve 1 row from a database table here, 3 there, insert a few lines into a third table or update a row of yet another table.

Most of OLTP-type applications are interactive: you press a button and expect the system to respond within a few seconds at most. That presents a challenge if the application is a multi-user system with hundreds of users working at the same time. It is not uncommon for an OLTP system to crunch tens of thousands, even millions of database operations per minute. And because of that these operations need to be extremely fast.

Therefore OLTP systems are specifically engineered for a low latency in conditions of high volume of elementary database operations.

Now imagine that at the end of the financial year the COO of the supermarket chain requires a detailed sales report. He wants to know which products were selling faster comparing to the previous 10 years with a breakdown by geographical areas. He also wants to know the correlation between the increased prices and sales volumes aggregated by product categories, and so on. Every business requires hundreds and hundreds of such reports, and not just at the end of the financial year but sometimes every day. Financial departments, sales, marketing, and management – they all want to know how the business is doing. In fact, there is a special buzzword for that kind of reporting – “Business Intelligence”. Another buzzword “Data mining” means “Looking for answers for which we don’t know questions yet”. Data mining looks for trends within the data and tries to find correlations to the known parameters. An example of a data mining query is “Find out if the sales volume changed within the last year and what else is changed that could explain that”.

Business Intelligence and Data Mining reports tend to be highly complex. Most of times they require querying data across very large datasets, such as all sales over the last 10 years,  then aggregating it, then calculating summaries, averages, correlations and so on. These are very different types of operations from which OLTP systems are designed for. And that is why running them against OLTP databases is usually not a good idea. This is what data warehouses are for.

Data warehouses are database systems optimised for complex database queries over large data sets.  They are predominantly used for Business Intelligence and Data Mining reporting. Within large corporate data warehouses it is common to have “sections” designed for specific purpose, for example for particular types of financial reports. These sections along with their business intelligence logic are called Datamarts.

Data warehouses usually source data from multiple systems. For example, sales data, financial data, inventory, vendors, etc. may come from different geographically distributed platforms which otherwise don’t talk to each other. Having all this information in one data warehouse enables business users to get reports such as profits on sales of certain goods per supplier.
